Gas Or Steam Heating Industrial Tumble Dryer

Gas Or Steam Heating Industrial Tumble Dryer

industrial tumble dryer gas heating

industrial tumble dryer steam heating

industrial tumble dryer with warranty

Lugar de origen:

Shanghai, China

Nombre de la marca:

YASEN

Éntrenos en contacto con
Solicitar una cita
Detalles del producto
Nombre del producto:
Secadoras de agua para uso industrial
Garantía:
1 año
Tipo de calefacción:
Gas o vapor
Fuerza:
0.55 y 2.2
Peso:
Entre 420 kg y 1250 kg
Tipo:
Las demás máquinas
Capacidad nominal:
Entre 15 y 120 kg
Fuente de alimentación:
Las emisiones de gases de efecto invernadero se calcularán en función de las emisiones de gases de e
Potencia del motor:
1.1kw
Presión de vapor:
0.4-0.6 MPa
Condiciones de pago y envío
Cantidad de orden mínima
1 por ciento
Precio
$2,500.00 - $7,500.00/sets
Detalles de empaquetado
Envases de madera para lavadoras
Capacidad de la fuente
100 conjuntos/conjuntos por mes
Descripción del producto
  1. Stainless steel drum, prevent the pollution of corrosion to fabric.
  2. High effeciency heat-exchanger,long service life.
  3. Large plush collection network, collect fluff easily and quickly.
  4. Large door, easy loading and unloading, opens 180°, option:left or right opening.
  5. Optimal design of cooling fan, with the best heat dissipation, wind speed.
  6. Heating type: electricity, steam, natural gas or coal.

Product Parameters:


Name: Tumble Dryer
HG SeriesModel
AttributesHG-300HG-400HG-500HG-700HG-1000HG-1400HG-2000GTH-120Z
Rated Capacity(kg)152025355070100120
Drum Dimension(mm)Φ800x600Φ900x650Φ970x670Φ970x1000Φ1180x870Φ1280x950Φ1450*1050
Motor Power(kw)0.550.550.750.751.11.52.2
Drying Speed(r/min)48454038353028
Fan Power(kw)0.550.550.750.751.11.51.5x2
Heating Power(kw)13182432395083
Rated Voltage(V)

220/380

/415

220/380

/415

220/380

/415

220/380

/415

220/380

/415

220/380

/415

220/380

/415

220/380

/415

Steam Pressure(Mpa)0.4-0.60.4-0.60.4-0.60.4-0.60.4-0.60.4-0.60.4-0.60.4-0.6
Consumes of Steam(kg/h)42427098120180250
Steam lnlet(lnch)G3/4"G3/4"G1"G1"G1.5"G2"G2"
Gas Consumption(m³/h)8.5m³
Gas lnlet(lnch)G1“
Dimension(L.W.H) (mm)

850x1100

x1600

880x1170

x1650

1060x1250

x2000

1100x1500

x2060

1310x1550

x2200

1405x1560

x2300

1660x1950

x2550

N.W.(kg)4204304504805608501250

Application Scenarios:

  • Hotel & Resort Laundry Operations
  • Hospital & Healthcare Linen Services
  • Uniform & Textile Rental Companies
  • Food & Beverage Industry Laundry
  • Sports & Fitness Facility Towel Services
  • Military & Correctional Facility Laundry
  • Industrial Workwear Cleaning Plants

Q&A: Industrial Tumble Dryer

Q: What are the common heating methods available for industrial tumble dryers?
A: The primary heating options include gas, steam, and electric. Gas-fired models typically offer lower operating costs, steam heaters are ideal for facilities with existing steam boilers, and electric dryers provide simplified installation.
Q: How is the capacity of an industrial tumble dryer selected for commercial use?
A: Capacity selection is based on daily laundry volume. Standard models range from 30 lbs (14 kg) to 200 lbs (90 kg). Sizing should be calculated according to peak operational loads to ensure efficient processing.
Q: In which operational contexts are industrial tumble dryers typically deployed?
A: These dryers are standard equipment in commercial and institutional laundries, including hotels, healthcare facilities, and industrial plants requiring high-volume textile processing.
Q: What energy-efficient features are incorporated in modern industrial tumble dryers?
A: Advanced models include moisture-monitoring systems that automatically terminate the cycle when the desired dryness level is achieved, preventing over-drying. Some gas-fired units also utilize two-stage heating systems that modulate energy output based on load requirements.
Q: What are the characteristics of the control systems in industrial tumble dryers?
A: Control systems range from basic dual digital timers to sophisticated programmable controllers capable of storing up to 41 automated drying programs. Advanced systems support plain-text programming for intuitive operation and recipe management.
Q: What safety features are integrated into industrial tumble dryers?
A: Beyond standard safety interlocks, optional automatic fire suppression systems (such as the C.A.R.E.® system) can be specified. These systems activate water deluge and remote alarms upon detecting combustion within the cylinder.
Q: What maintenance protocols are recommended for industrial tumble dryers?
A: Regular lint filter cleaning is essential. Additionally, adherence to manufacturer-recommended service intervals for systematic inspection and component maintenance is crucial for long-term operational reliability.

Gas Or Steam Heating Industrial Tumble Dryer 0Gas Or Steam Heating Industrial Tumble Dryer 1

Gas Or Steam Heating Industrial Tumble Dryer 2

Gas Or Steam Heating Industrial Tumble Dryer 3 Gas Or Steam Heating Industrial Tumble Dryer 4

Gas Or Steam Heating Industrial Tumble Dryer 5
